AWS Services - Glacier

What is Amazon S3 Glacier?

Amazon S3 Glacier is a low-cost cloud storage service for data archiving and long-term backup. It is optimized for data that is infrequently accessed and for which retrieval times of minutes to hours are acceptable.

Key features:

  • Extremely low storage cost compared to S3 Standard
  • Designed for long-term retention (years/decades)
  • Retrieval options:
    • Expedited (1–5 minutes, higher cost)
    • Standard (3–5 hours)
    • Bulk (5–12 hours, lowest cost)
  • Use cases:
    • Compliance and regulatory archives
    • Backups
    • Digital preservation

Creating a Glacier Vault

Using AWS Console (GUI)

  1. Go to AWS Management Console → S3 Glacier.
  2. Click Create Vault.
  3. Choose a region.
  4. Enter a vault name (e.g., myvault).
  5. Optionally configure notifications or tags.
  6. Click Create Vault.

Using AWS CLI

aws glacier create-vault --account-id - --vault-name myvault

Uploading Data to Glacier

Unlike S3 Standard storage, Glacier does not allow direct object upload from the console. You must use:

  • AWS CLI
  • AWS SDKs
  • Lifecycle policies (transitioning S3 objects into Glacier)

Example: Multipart Upload with AWS CLI

1. Create a Large File (3 MB)

dd if=/dev/urandom of=largefile bs=3145728 count=1

2. Split File into 1 MB Chunks

split --bytes=1048576 --verbose largefile chunk

Produces: chunkaa, chunkab, chunkac.

3. Initiate Multipart Upload

aws glacier initiate-multipart-upload --account-id - --archive-description "multipart upload test" --part-size 1048576
--vault-name myvault

Response:

{
  "location": "...",
  "uploadId": "ssW0Kx..."
}

4. Assign Upload ID and Upload Parts

UPLOADID="ssW0Kx..."

aws glacier upload-multipart-part
--upload-id $UPLOADID --body chunkaa --range 'bytes 0-1048575/*' --account-id - --vault-name myvault

aws glacier upload-multipart-part --upload-id $UPLOADID --body chunkab --range 'bytes 1048576-2097151/*' --account-id -
--vault-name myvault

aws glacier upload-multipart-part --upload-id $UPLOADID --body chunkac --range 'bytes 2097152-3145727/*' --account-id -
--vault-name myvault

5. Generate Checksums for Each Part

openssl dgst -sha256 -binary chunkaa > hash1
openssl dgst -sha256 -binary chunkab > hash2
openssl dgst -sha256 -binary chunkac > hash3

6. Combine Hashes

cat hash1 hash2 > hash12
openssl dgst -sha256 -binary hash12 > hash12hash

cat hash12hash hash3 > hash123
openssl dgst -sha256 hash123

Result:

SHA256(hash123)= 9628195f...

Assign to variable:

TREEHASH=9628195f...

7. Complete Multipart Upload

aws glacier complete-multipart-upload --checksum $TREEHASH --archive-size 3145728 --upload-id $UPLOADID --account-id -
--vault-name myvault

Retrieving Data from Glacier

Data in Glacier cannot be instantly retrieved. You must initiate a retrieval job.

Example:

aws glacier initiate-job --account-id - --vault-name myvault --job-parameters '{"Type": "archive-retrieval", "
ArchiveId": "ARCHIVE_ID"}'

Then check job status:

aws glacier describe-job --account-id - --vault-name myvault --job-id JOB_ID

Once completed, download the archive:

aws glacier get-job-output --account-id - --vault-name myvault --job-id JOB_ID output_file.txt

Lifecycle Policies with S3 + Glacier

Often, instead of directly uploading to Glacier, organizations:

  • Store objects in S3 Standard first
  • Define a lifecycle policy to transition them into S3 Glacier or S3 Glacier Deep Archive after a number of days

Example use case:

  • Keep logs in S3 Standard for 30 days
  • Move them to Glacier for 1 year
  • Finally, move them to Glacier Deep Archive for long-term retention

Additional Notes

  • Glacier Vault Lock: Provides compliance controls (e.g., write-once-read-many, WORM).
  • Pricing: Very cheap storage, but retrieval and early deletion (less than 90 days) have additional costs.
  • Alternatives: For infrequently accessed but still “hot” data, consider S3 Glacier Instant Retrieval or S3 Glacier Flexible Retrieval storage classes instead of pure Glacier vaults.
